74LS114
Dual JK negative-edge-triggered flip-flops with preset, common clear and common clock
Pinout:
Default
Style:
GOST
Variant:
Variant 1
PDIP-14
(JEDEC MS-001, Variation AA)
Pinout
Manufacturer:
Texas Instruments
Part number:
SN74LS114A
PDIP-14 (JEDEC MS-001, Variation AA)
package diagram
